LPG Gas Model : TG-TC2 ( Optional : Electic , LPG , Diesel )
|
Inner size
|
1500*800*800mm
( L*W*H)
|
Outter size
|
1800*1100*1100mm
( L*W*H)
|
Total power
|
3 Kw
|
Door type
|
One sided ( Optional : two sided )
|
Panel
|
Outer wall : Galvanized
steel, Electrostatic spraying
Inner
wall : SUS#304 stainless steel
The
middle with 150mm thickness rock wool board insulation layer
|
Heating system
|
LPG Gas Burner, Italy
Riello or BT burner
Heating time : 20-30 min (150-250℃)
Voltage :,380V/415V , 50/60HZ
|
Tempe. control accuracy
|
±1°C
|
Temp.-range
|
Rm. Temp~250℃
|
Temp. uniformity
|
±2°C
|
Circulation system
|
1 set ,3Kw
high-temperature fan
1 set Vaporization furnace
|
Control system
|
Temperature alarm;Thesensorsystem,Stop button;Process setting system:
temperature stop automatically .
|
Accessories
|
Complete seal device, door
,lock .etc.
|
