Inner size could be customized accorditing to materials and requirements
Diesel Model : TG-TC3 ( Optional : Electic , LPG , Diesel ) Inner size 1800*1600*1200mm ( L*W*H) Outter size 2100*1900*1500mm ( L*W*H) Total power 3 Kw Door type One sided ( Optional : two sided ) Panel Outer wall : Galvanized steel, Electrostatic spraying Inner wall : SUS#304 stainless steel The middle with 150mm thickness rock wool board insulation layer Heating system Diesel Burner, Italy Riello or BT burner Heating time : 20-30 min (150-250℃) Voltage :,380V/415V , 50/60HZ
Diesel Model : TG-TC3 ( Optional : Electic , LPG , Diesel )
Inner size
1800*1600*1200mm ( L*W*H)
Outter size
2100*1900*1500mm ( L*W*H)
Total power
3 Kw
Door type
One sided ( Optional : two sided )
Panel
Outer wall : Galvanized steel, Electrostatic spraying
Inner wall : SUS#304 stainless steel
The middle with 150mm thickness rock wool board insulation layer
Heating system
Diesel Burner, Italy Riello or BT burner
Heating time : 20-30 min (150-250℃)
Tempe. control accuracy
±1°C
Temp.-range
Rm. Temp~250℃
Temp. uniformity
±2°C
Circulation system
1 set ,3Kw high-temperature fan
1 set Vaporization furnace
Control system
Temperature alarm;Thesensorsystem,Stop button;Process setting system: temperature stop automatically .
Accessories
Complete seal device, door ,lock .etc.
