TECHNICAL DATA
Rim Diamter
14" - 26"
Max.wheel weight
500kg
Max Wheel Width
780mm
Max Tyre Diameter
1600mm
Hydraulic Pump Motor
1.5KW 380V - 3PH(220V Optional)
Gearbox Motor
2.2KW 380V - 3PH(220V Optional)
Bead Breaker Force
2500kg
Max.Torque
6457N.m
Operation Control Voltage
24V
Machine Weight Approx
517kg
Overall Dimensions Approx
2500×2000mm
Power
220/400V 50/60HZ 1P/3P Optional
