Combined Type Screw Air Compressor TG-11-4H

Specifications :

Combined Type Screw Air Compressor TG-11-4H

Power: 15HP/11kw

Exhaust Volume : 1.6m³/min

Working Pressure : 0.8Mpa/8Kg

Noise:  62db(±2)

Compression method: Trace oil, first stage compression

Cooling method: Radiator air cooling method

Motor speed: N=3000r/min

Lube: 12L

Fuel consumption : ≤2PPM

Compressed air outlet temperature : 10-15℃ higher than ambient temperature

Start Mode: Variable frequency soft start and automatic speed regulation

Control system : Computer LCD touch screen

Gas tank capacity: 400L

High precision filter : 2Pcs

Voltage : 220V/380V/400V/415V , 3Phase, 50/60HZ

Size: 1600*780*1600mm

Weight :350kgs
