Combined Type Screw Air Compressor TG-15-4H
|
Power
|
20HP/15KW
|
Exhaust Volume
|
2.5m³/min
|
WorKing Pressure
|
0.8MPA/8KG
|
Noise
|
62db(±2)
|
Compression method
|
Trace oil, first stage compression
|
Cooling method
|
Radiator air cooling method
|
Motor speed
|
N=3000r/min
|
Lube
|
12L
|
Fuel consumption
|
≤2PPM
|
Compressed air outlet temperature
|
10-15 ℃ higher than ambient temperature
|
Start Mode
|
Variable frequency soft start and automatic speed regulation
|
Control system
|
Computer LCD touch screen
|
Gas tank capacity
|
400L
|
High precision filter
|
2 Pcs
|
Voltage
|
220/380/415V, 3Phase, 50/60HZ
|
Size
|
1600mm*780mm*1600mm(L*W*H)
|
Weight
|
350KG
|
